Filtering Coal Pollution: Effective Methods For Cleaner Air

Coal-fired power plants are a major source of air pollution, emitting harmful pollutants such as particulate matter (PM), carbon monoxide, lead, sulfur dioxide (SO2), nitrogen oxides (NOx), and mercury. These pollutants have significant health impacts, including lung damage and premature death. While steps have been taken to reduce coal plant emissions, such as the Clean Air Act and the use of modern technologies, the high volume of coal usage continues to contribute to air pollution. To address this issue, various methods can be employed, including the implementation of pollution controls, the adoption of clean energy sources, and public education to reduce the harmful effects of coal air pollution.

Using Selective Catalytic Reduction to remove nitrogen oxides

Nitrogen oxides (NOx) are one of the six "criteria pollutants" produced by coal-fired power plants, along with carbon monoxide, lead, sulfur dioxide, ground-level ozone, and particulate matter. NOx contributes to acid rain and the formation of harmful ground-level ozone and photochemical smog.

Selective Catalytic Reduction (SCR) is a technology used to reduce the emission of nitrogen oxides from coal-fired power plants, diesel engines, and other industries. It is considered the most efficient technology for this purpose. SCR is a secondary method of removing NOx, conditioning the exhaust gas after the combustion process to reduce the nitrogen oxides formed during combustion.

The cost of SCR equipment to remove nitrogen oxides ranges from $424 per kilowatt for a unit less than 100 megawatts to $193 per kilowatt for a unit that is 700 megawatts or larger.

One example of the successful implementation of SCR is in the B&W-5L90MC slow-speed marine diesel propulsion engine. The efficiency of the SCR system was tested using a full-mission simulator, and the results showed a 95% reduction in NOx in the exhaust gas after being treated through an SCR reactor.

In addition to SCR, other technologies used to reduce NOx emissions include fuel emulsions, water injection systems, and engine modifications.

Adding SO2 scrubbers to remove sulfur dioxide

Coal-burning power plants produce energy for millions of residences and commercial facilities worldwide. However, coal burning is a major contributor to air pollution, especially in developing countries where proper pollution controls are not in place. One of the harmful pollutants emitted by coal-burning plants is sulfur dioxide (SO2), which can cause respiratory issues and contribute to acid rain and particulate matter pollution.

To address this issue, SO2 scrubbers, also known as flue-gas desulfurization systems, can be added to remove sulfur dioxide from the emissions. These systems use limestone or other reagents like NaOH, lime, or sodium bicarbonate to react with and neutralize the SO2, producing calcium sulfite or sulfate as a byproduct. This process prevents the release of SO2 into the environment and helps improve air quality.

There are two main types of SO2 scrubbers: dry and wet purification techniques. Dry purification methods employ adsorbers, while wet methods utilize spray tower scrubber systems, packed bed absorbers, or fluidized bed absorbers. Wet scrubbers are generally more effective in removing SO2 and can capture pollutants as small as 0.1 microns. Packed bed scrubbers, a type of wet scrubber, are often preferred due to their lower cost and higher efficiency compared to other scrubber types.

When designing an SO2 scrubber system, engineers consider the specific application and existing equipment to recommend the most suitable packing materials, scrubber design, and process. The scrubber system can be customized to fit the industrial setup, ensuring compliance with sulfur dioxide emission regulations.

By installing SO2 scrubbers, coal-fired power plants can significantly reduce their sulfur dioxide emissions and minimize their environmental impact. This technology plays a crucial role in improving air quality and mitigating the harmful effects of coal-burning power plants on human health and the environment.

Installing activated carbon injection systems to remove mercury

Coal-burning power plants produce energy for millions of residences and commercial facilities worldwide. However, the high volume of coal used releases pollutants into the air, causing lung damage and other serious health issues. To mitigate these negative impacts, power plants can install activated carbon injection (ACI) systems to specifically target and remove mercury from their emissions.

ACI technology has been available since 2005, and it is now considered the most effective method for mercury removal in coal-fired power plants. The ACI process involves injecting activated carbon in front of existing particulate control devices to capture mercury. This technology can achieve up to 99% removal of mercury, significantly reducing its release into the atmosphere.

To ensure the success of ACI systems, several factors must be considered. Firstly, the impact of technologies aimed at controlling other pollutants, such as SO3, needs to be understood, as this can influence particulate control. Secondly, techniques to assure the quality of delivered carbon must be employed, and techniques to improve the effectiveness of activated carbon should be explored. Additionally, the development of facilities to produce an additional carbon supply can support the continued implementation of ACI technology.

The installation of ACI systems is a complex process that requires experienced designers and engineers. Companies such as LDX Solutions have designed and supplied ACI systems for various industries, including coal-fired boiler operations. These systems are tailored to each client's needs, utilizing CFD modeling to ensure even distribution of carbon. By addressing carbon flow, reducing carbon leakage, and minimizing wear and pluggage, ACI systems can effectively optimize mercury removal and contribute to cleaner air.

Overall, the adoption of ACI technology in coal-fired power plants is a significant step towards reducing mercury emissions and mitigating their harmful effects on human health and the environment. With continued advancements and widespread implementation, ACI systems can play a crucial role in improving air quality and protecting public health on a global scale.

Reducing NOx emissions through state-led initiatives

Nitrogen oxides (NOx) are a family of poisonous, highly reactive gases that are emitted from automobiles, trucks, construction equipment, industrial boilers, and other sources. NOx emissions contribute to air pollution and have harmful effects on human health and the environment. To address this issue, state governments in the US have implemented various initiatives to reduce NOx emissions and improve air quality.

One example of a successful state-led initiative is the Regional Greenhouse Gas Initiative (RGGI) formed in 2009 by 10 states in the Northeast, including Connecticut, Delaware, and New York. The RGGI is a collaborative effort to reduce greenhouse gas emissions and reinvest revenues from carbon reduction programs into pollution reduction technologies, renewable energy sources, and energy efficiency initiatives. This program has influenced other states to adopt similar measures, demonstrating the impact of state leadership in driving climate action.

Additionally, 43 states and Washington, D.C., took actions related to electric vehicles (EVs) and charging infrastructure in 2019. California, a leader in climate policy, implemented a zero-emission vehicle standard, requiring automakers to sell a certain percentage of zero-emission vehicles. This initiative was joined by 12 other states, promoting the adoption of EVs and reducing NOx emissions from traditional combustion engines.

Furthermore, states like California have enacted Buy Clean standards, considering suppliers' greenhouse gas emissions when purchasing materials for infrastructure projects. This policy encourages the use of cleaner production methods and reduces emissions associated with industrial activities, which contribute significantly to NOx emissions.

While state-led initiatives have made significant progress in reducing NOx emissions, more work needs to be done to address the cumulative impacts of toxic pollution on disadvantaged communities. Climate action plans, clean vehicle policies, and emission reduction targets adopted by multiple states demonstrate a commitment to reducing greenhouse gas emissions and improving air quality. These state-led efforts are vital in the absence of stronger federal action and provide a foundation for future national and international responses to climate change.

Improving technology to reduce criteria pollutants

Coal-fired power plants are a major source of air pollution, releasing harmful pollutants such as particulate matter (PM), carbon dioxide, mercury, sulfur dioxide (SO2), and nitrogen oxides (NOx). These pollutants have significant impacts on human health, contributing to lung damage, asthma, and even premature deaths. However, improving technology plays a crucial role in reducing these criteria pollutants and mitigating the environmental and health consequences associated with coal-fired power generation.

One effective technology is the use of Selective Catalytic Reduction (SCR) systems. SCR technology involves injecting a reducing agent, such as ammonia or urea, into the flue gas stream of a coal-fired boiler. This process helps convert nitrogen oxides (NOx) into harmless nitrogen gas (N2) and water vapour (H2O). SCR systems have proven highly successful in reducing NOx emissions, with reported reductions of up to 86% compared to uncontrolled plants.

Another technology employed in coal-fired power plants is flue gas desulfurization (FGD). FGD systems aim to remove sulfur dioxide (SO2) from the flue gas before it is released into the atmosphere. By installing FGD equipment, power plants can achieve significant reductions in SO2 emissions, contributing to improved air quality and reduced acid rain formation. The cost of implementing FGD technology varies depending on the unit size, with smaller units (<100 megawatts) incurring higher costs per kilowatt.

Activated carbon injection systems are also used specifically for mercury removal. Mercury is a highly toxic pollutant released during coal combustion, and by injecting activated carbon upstream of particulate control devices, plants can effectively capture and remove mercury from the flue gas stream. Additionally, dry and wet electrostatic precipitators help remove particulate matter (PM) by using electric forces to attract and collect the charged particles, further reducing air pollution.

Furthermore, shifting towards cleaner energy sources, such as natural gas, can also contribute to reducing criteria pollutants. Natural gas power plants primarily produce nitrogen dioxide (NO2) emissions, which can be reduced by up to 90% with proper controls. By transitioning away from coal-fired power plants, which are responsible for a significant portion of power plant emissions, countries can significantly decrease the overall emission of criteria pollutants.

In summary, improving technology plays a pivotal role in reducing criteria pollutants from coal-fired power plants. By implementing Selective Catalytic Reduction, flue gas desulfurization, activated carbon injection, electrostatic precipitators, and transitioning to cleaner energy sources, significant strides can be made in mitigating air pollution and improving public health outcomes.
