Vehicle Filters: Effective Pollution Solution?

Air pollution is a serious issue, with the World Health Organization (WHO) declaring it the primary environmental risk. Vehicle emissions are a significant contributor to this problem, and the pollution levels inside a vehicle can be up to five times higher than the accepted exposure limits for harmful gases and pollutants. This is due to the concentration of pollutants increasing in enclosed spaces, and the belief that rolling up windows can protect against pollution is a myth. However, there is growing awareness of the health effects of vehicle emissions, and researchers have designed filters to combat in-car air pollution. These filters aim to remove dangerous exhaust fumes, such as nitrogen dioxide (NO2), and particulate matter, which can cause serious health issues. The effectiveness of these filters varies, and factors such as temperature, humidity, and the presence of an activated carbon filtering element influence their performance. Additionally, regular maintenance and filter changes are crucial for maintaining clean air inside vehicles.

Vehicle Filters and Pollution Characteristics

Air filters with small fibres can trap large amounts of particulate matter

Vehicle air filters are designed to reduce in-car air pollution. They are particularly effective at removing particulate matter, which makes up a large proportion of pollutants emitted from cars. These particles can be harmful to human health, causing issues such as stroke, heart disease, lung cancer, and respiratory infections.

While traditional filters can struggle to capture very small particles, new cabin filters with small fibres have been shown to trap large amounts of particulate matter, including ultrafine particles (UFPs). These UFPs, which are less than 100 nm in diameter, can penetrate deeper into the lungs than other particles and have been linked to asthma attacks and heart disease. The small fibres in the new filters block more UFPs, improving the air quality inside vehicles.

The effectiveness of air filters depends on various factors, including fibre diameter, filter thickness, and face velocity. HEPA filters, for example, are designed to remove at least 99.97% of particles with a size of 0.3 microns or larger. These filters are made of dense, tightly woven materials that can trap even the tiniest particles. However, they may not be effective against gases, odours, certain viruses, and chemicals.

To improve the performance of vehicle air filters, it is recommended to combine them with other technologies such as activated carbon or charcoal filters. These can help remove nitrogen dioxide (NO2) and hydrocarbon pollutants, further enhancing the air quality inside vehicles. Additionally, regularly changing the cabin filter, every six months to a year, can also improve the air quality.

Overall, air filters with small fibres have been proven to effectively trap large amounts of particulate matter, including UFPs, reducing the health risks associated with vehicle pollution.

Filters with activated carbon can remove nitrogen dioxide and hydrocarbons

Vehicle air pollution is a pressing issue, with pollutants from cars linked to major health issues such as stroke, heart disease, lung cancer, and respiratory infections. While rolling up windows or switching on the air recirculation function can help, these are not long-term solutions. A more effective approach is to use high-performance filters that can trap harmful exhaust particles.

Filters with activated carbon, also known as charcoal filters, are highly effective at removing nitrogen dioxide (NO2) and hydrocarbons from the air. These filters work by allowing air to flow through a paper and carbon filter media, where gases and odors come into contact with the activated carbon. The microscopic particles then physically bond to the surface of the carbon due to its chemical properties. This process is known as adsorption, where the molecules are attracted and retained by the activated carbon.

The effectiveness of activated carbon filters in removing nitrogen dioxide can be as high as 90% compared to outside levels, and they can cut down levels of NO2 and hydrocarbons by 75% and 50%, respectively. However, it is important to note that the efficiency of these filters can be impacted by temperature and relative humidity. When the ambient humidity exceeds 50%, the ability of activated carbon to function efficiently is reduced, and at humidity levels above 75%, the filter becomes even less efficient.

Additionally, the production of activated carbon can have detrimental environmental impacts, and the filters themselves require regular maintenance. Over time, the pores in the carbon can become filled, and the filter can become saturated, reducing its effectiveness. As a result, it is recommended to change the filter every six to twelve months, depending on usage.

While activated carbon filters are a significant improvement over standard filters, they are not perfect. Some pollutants, such as super-tiny exhaust particles, may still penetrate and contribute to health issues. Researchers are continuously working on improving filtration systems, and new cabin filters with smaller fibers have shown promising results in trapping larger amounts of particulate matter, especially ultrafine particles.

The A/C system's 'air recirculation' function can reduce cabin levels of particulate pollutants

Vehicle filters can help reduce in-car air pollution. However, not all car cabin filters are created equal. Factory-installed cabin air filters can remove about 46% of particulate pollution, but they do not filter out nitrogen dioxide (NO2) or hydrocarbon pollutants.

An EU-funded project called NOXTEK has designed an anti-pollution filter that removes dangerous exhaust fumes such as nitrogen dioxide (NO2) from inside vehicles. This filter uses cutting-edge nanomaterials and acts as a highly effective molecular sieve for removing NO2 from polluted air flows.

Another approach to reducing exposure to particulate matter is to isolate the driver from the outside air, which can be achieved through the A/C system's "air recirculation" function. This function shuts down the air exchange between the inside and outside of the vehicle and instead uses recirculated air, reducing the cabin's levels of particulate pollutants by up to 90%.

It is important to note that recirculating air can lead to a buildup of exhaled carbon dioxide (CO2), which can cause negative side effects such as poor decision-making, drowsiness, headaches, and mild nausea. To mitigate this, it is recommended to turn off the recirculation function for a brief period to allow CO2 to dissipate before turning it back on.

In addition to using the air recirculation function, upgrading to a high-efficiency cabin air filter with an activated carbon element can further improve air quality. These filters can cut down levels of NO2 and hydrocarbons by 75% and 50%, respectively. However, it can be challenging to find an effective filter, and they typically require more frequent replacement and have a higher cost.

Overall, the A/C system's air recirculation function can effectively reduce cabin levels of particulate pollutants, but it is important to balance this with occasional air exchange to maintain safe CO2 levels. Upgrading to a high-efficiency cabin air filter can also help improve the overall air quality in the vehicle.

Temperature and humidity impact the adsorption capacity of cabin air filters

Vehicle filters can help reduce in-car air pollution. The EU-funded NOXTEK project, for example, has designed an anti-pollution filter that removes dangerous exhaust fumes such as nitrogen dioxide (NO2) from inside vehicles. Similarly, researchers have shown that new vehicle air filters are better at trapping potentially harmful vehicle exhaust particles less than 100 nm in diameter.

Relative humidity is another critical factor influencing filter efficiency. When ambient humidity exceeds 50%, the ability of activated carbon to function efficiently is severely affected, and at humidity levels above 75%, the filter becomes less effective. This is because the molecules of gases with low boiling points will be less adsorbed due to the presence of water vapour molecules, resulting in reduced available surface area in the pores for gas molecules to impact the carbon. Therefore, relative humidity should be maintained below 60%.

The efficiency of carbon filters is also influenced by other factors such as residence time, filter age, and the rate of evaporation and concentration of chemical vapours. Overall, temperature and humidity play a significant role in the adsorption capacity of cabin air filters, and maintaining optimal temperature and humidity levels is crucial for ensuring the effectiveness of these filters in reducing vehicle pollution.

High-efficiency particulate air (HEPA) filters can mitigate the risks of traffic pollution

Vehicle air pollution poses a serious health risk, with exposure to pollutants leading to major health issues such as stroke, heart disease, lung cancer, and respiratory infections. While rolling up the windows of a vehicle may be an intuitive response to air pollution, it is not an effective solution.

High-efficiency particulate air (HEPA) filters are a type of mechanical air filter designed to effectively trap very fine particles. HEPA filters are rated based on their ability to capture particles of a specific size, with the worst-case efficiency rating being 99.97% or better for all particle sizes. This means that HEPA filters are even more efficient at capturing smaller particles, such as those the size of viruses. The random, dense arrangement of fibers in the HEPA filter helps to catch a range of particle sizes through diffusion, interception, and impaction.

HEPA filters can be used in vehicles to improve air quality by trapping harmful exhaust particles. Researchers have tested the effectiveness of HEPA filters in vehicles, finding that they outperform manufacturer-installed filters. The use of HEPA filters can reduce the health risks associated with exposure to traffic pollution, such as the risk of asthma attacks or worsened heart disease.

It is important to note that HEPA filters do not filter out gasses and odor molecules. In circumstances where the filtration of volatile organic compounds or chemical vapors is required, an activated carbon or charcoal filter may be used in addition to a HEPA filter. Additionally, the effectiveness of HEPA filters in vehicles can be enhanced by using the air recirculation function, which reduces the exchange of air between the inside and outside of the vehicle. However, it is important to periodically turn off the recirculation function to prevent a buildup of carbon dioxide.
