Air Pollution Control Devices: How Do They Work?

Air pollution control devices are a series of devices that work to prevent gaseous and solid pollutants from entering the atmosphere, primarily from industrial smokestacks. These devices can be split into two categories: those that control the amount of particulate matter escaping into the environment and those that control acidic gas emissions. Devices such as scrubbers, electrostatic precipitators, fabric filters, oxidizers, and mist collectors are all used to remove harmful materials from industrial exhaust gases before they are released into the environment.

Electrostatic precipitators remove soot and ash from exhaust fumes

Air pollution control devices are a series of devices that work to prevent various pollutants, both gaseous and solid, from entering the atmosphere, primarily from industrial smokestacks. These devices can be broadly categorized into two types: devices that control the amount of particulate matter escaping into the environment, and devices that control acidic gas emissions.

Electrostatic precipitators are a type of air pollution control device that uses static electricity to remove soot and ash from exhaust fumes before they exit the smokestacks. They are highly effective, capable of removing more than 99% of particulate matter. The basic principle behind their functioning is electrostatic attraction. As smoke and gas are pumped out of a furnace or burner, they pass over a wire or plate and gain a static charge. The charged particles are then collected on a second plate with an opposite charge, where they are trapped. The shape of these electrodes can vary depending on the type of electrostatic precipitator used, but they are typically metal wires, bars, or plates inside a pipe or the smokestack itself. One of the electrodes is charged with a high negative voltage, which causes the particulates inside the smoke to obtain a negative charge as they pass by. Further along, the second electrode carries a high positive voltage, attracting the negatively charged soot particles, which stick to it.

Electrostatic precipitators are commonly used in power plants that burn fossil fuels such as coal or oil to generate electricity. When these fuels undergo combustion, smoke is produced, which consists of tiny particles of soot suspended in hot, rising air. These unburned particles of carbon are pulled out of the smoke by the precipitators, leaving clean, hot air to escape the smokestacks. It is crucial to remove this unreacted carbon from the smoke, as it can damage buildings and harm human health, especially respiratory health.

Despite their effectiveness, electrostatic precipitators have some limitations. They are challenging and messy to clean, as the dust and smoke particles collected inside need to be manually removed. Additionally, they may not be suitable for home use due to the risk of ozone production. Furthermore, particles with very high or very low resistivity can be challenging for these devices to handle effectively; they perform best with particulate matter of moderate resistivity.

Scrubbers remove gaseous pollutants like sulfur dioxide

Air pollution control devices are a series of devices that work to prevent various pollutants, both gaseous and solid, from entering the atmosphere, primarily from industrial smokestacks. These devices can be categorised into two groups: devices that control the amount of particulate matter escaping into the environment, and devices that control acidic gas emissions.

One such device is the scrubber, which is specifically designed to remove pollutants from industrial exhaust gases. Scrubbers are commonly used to remove both traditional and novel classes of air pollutants. They are particularly effective at targeting and removing gaseous pollutants like sulfur dioxide (SO2), nitrogen oxides (NOx), and particulate matter (PM).

Wet scrubbers, for example, use liquid solvents to remove pollution from air or liquid. The contaminated gas enters at the bottom of the scrubber and passes upward through a packed bed and downward-flowing solvent sprays. The pollutants are collected in the solvent droplets, and before the gas leaves the scrubber, it passes through a mist eliminator to capture any remaining droplets. Wet scrubbers can remove organic and inorganic pollutants, including those that cause illness, deplete the ozone layer, or disrupt ecosystems.

A specific type of wet scrubber is the sulfur dioxide scrubber, or flue gas desulfurization (FGD) technology, which removes or "scrubs" SO2 emissions from the exhaust of coal-fired power plants. This type of scrubber works by spraying a wet slurry of limestone into a large chamber where the calcium in the limestone reacts with the SO2 in the flue gas. The reaction enables the SO2 to be removed before it is released into the atmosphere, and the byproduct, calcium sulfate, can be recycled for use in manufacturing or agriculture.

Oxidizers eliminate volatile organic compounds

Air pollution control devices are a series of devices that work to prevent a variety of different gaseous and solid pollutants from entering the atmosphere, primarily from industrial smokestacks. These devices can be categorised into two groups: devices that control the amount of particulate matter escaping into the environment and devices that control acidic gas emissions.

Oxidizers are a type of air pollution control device that eliminates volatile organic compounds (VOCs) and hazardous air pollutants (HAPs) from industrial exhaust gases. VOCs are chemicals in the air from industrial processes that must be cleaned before being released, according to the EPA. They are also found in everyday products such as cleaning products, air fresheners, paints, and cosmetics. VOCs can be harmful to both the environment and people, causing irritation to the eyes, nose, and throat, severe headaches, dizziness, and even certain types of cancers.

Oxidizers work by exposing these pollutants to high temperatures in the presence of oxygen, triggering a chemical reaction that converts the harmful compounds into less harmful byproducts. There are several types of oxidizers, including thermal, catalytic, and regenerative oxidizers. Thermal oxidizers, also known as incinerators or afterburners, destroy pollutants by heating and maintaining a polluted airstream at a high temperature for a set period of time. Catalytic oxidizers, on the other hand, use a catalyst integral to the system, allowing VOC oxidation to occur at a lower temperature, typically between 600-700°F. This lower operating temperature results in significantly reduced fuel consumption compared to thermal oxidizers.

While oxidizers are highly effective at eliminating VOCs, they have certain limitations. One primary concern is their high energy consumption, as achieving the necessary temperatures for effective oxidation requires a substantial amount of energy, which can increase operational costs. Additionally, the combustion of VOCs can result in the formation of new pollutants, such as nitrogen oxides (NOx), which can contribute to issues like ground-level ozone depletion and smog formation. To mitigate these issues, advanced oxidation processes (AOPs) can be employed, which involve the use of oxidants or oxidation catalysts to enhance the oxidation of VOCs and improve the removal of harmful byproducts.

Mist collectors capture liquid droplets from industrial exhaust streams

Air pollution control devices are a series of devices that work to prevent a variety of different pollutants, both gaseous and solid, from entering the atmosphere, primarily from industrial smokestacks. One such device is a mist collector, also known as an oil mist eliminator. These devices capture and remove liquid droplets or mists from industrial exhaust streams. They are particularly effective in handling pollutants such as oil mists, coolant mists, and fumes generated by metalworking, machining, and industrial cooling systems.

Mist collectors use mechanisms like impaction, interception, and coalescence to separate mist particles from the air. The captured mist particles merge into larger droplets, which can then be drained or collected for proper disposal. The most common type of mist collector is a wire mesh, which can be used for vertical or horizontal airflow. Vertical mist collectors are the most common, but horizontal mist collectors are often used in applications like battery manufacturing, chrome or nickel plating, and chromic anodizing.

The design and spacing of the vane blades in a mist collector depend on the specific application and the droplets being filtered. For example, the density of the gas versus the density of the vaporized liquid will affect the angle of the "chevrons" and the rate of impaction. The speed of the airflow is another important factor, as a faster gas stream can cause the droplets to be reabsorbed into the gas stream, a phenomenon known as re-entrainment. To prevent this, many vane mist eliminators have capture hooks and drainage hooks.

Mist collectors offer several benefits, such as improved air quality, reduced maintenance and housekeeping costs, improved product quality, and compliance with indoor air quality standards. However, it is important to note that mist collectors may struggle with high-viscosity mists, which can require specialized designs or additional pre-treatment steps.

Cyclones remove dust matter from gas streams

Air pollution control devices are a series of devices that work to prevent a variety of different pollutants, both gaseous and solid, from entering the atmosphere. Devices that control the amount of particulate matter escaping into the environment and devices that control acidic gas emissions are the two broad categories that these control devices can be separated into.

One such device is the cyclone separator, which uses the principle of inertia to remove dust matter from gas streams. Cyclone separators are found in all types of power and industrial applications, including pulp and paper plants, steel mills, petroleum coke plants, and metallurgical plants. Cyclones are also used in oil refineries to separate oils and gases, and in the cement industry as components of kiln preheaters.

Cyclonic separation is a method of removing particulates from an air, gas, or liquid stream, without the use of filters, through vortex separation. A high-speed rotating airflow is established within a cylindrical or conical container called a cyclone. Air flows in a helical pattern, beginning at the top (wide end) of the cyclone and ending at the bottom (narrow) end before exiting the cyclone in a straight stream through the center of the cyclone and out the top. The larger (denser) particles in the rotating stream have too much inertia to follow the tight curve of the stream, and thus strike the outside wall, then fall to the bottom of the cyclone where they can be removed.

Single-cyclone separators create a dual vortex to separate coarse from fine dust. The main vortex spirals downward and carries most of the coarser dust particles. The inner vortex, created near the bottom of the cyclone, spirals upward and carries finer dust particles. Multiple-cyclone separators, on the other hand, consist of several small-diameter cyclones operating in parallel, removing more dust than single-cyclone separators due to their longer length and smaller diameter, which result in better separation of dust particulates.
