Purifying Air: Reducing Pollution From Paper Production

Paper production is one of the most polluting industries in the world, impacting air, water, and land. Pulp and paper mills are large emitters of air pollution, releasing toxic gases such as carbon dioxide, nitrogen dioxide, sulfur dioxide, and carbon monoxide, which contribute to climate change, acid rain, and respiratory problems. Various toxic chemicals are used in paper production, including chlorine compounds for bleaching and delignifying pulp, and biocides like mercury to prevent bacterial growth. The pulp and paper industry also generates significant solid waste and sludge, consuming landfill space and contaminating soil and water bodies. To mitigate air pollution, regulations such as the National Emissions Standards for Hazardous Air Pollutants (NESHAP) have been established, and companies are exploring ways to reduce energy and water demand, recycle, and implement better technology.

Regulations for paper production: National Emission Standards for Hazardous Air Pollutants (NESHAP)

The pulp and paper industry is one of the most polluting industries in the world, particularly due to the discharge of hazardous chemical compounds present in wastewater after pulp and paper production. The industry's production processes emit dust, smoke, fumes, and gases that affect air quality.

To mitigate these issues, the National Emission Standards for Hazardous Air Pollutants (NESHAP) for the pulp and paper production sources were proposed in 1993 and promulgated in 1998. NESHAP is a set of stationary source standards for hazardous air pollutants (HAPs) that are known or suspected to cause cancer or other serious health and environmental effects. The EPA identified methanol, acetaldehyde, formaldehyde, and other hazardous air pollutants as being emitted in large quantities from these sources.

The NESHAP regulations for the pulp and paper industry focus on mills that chemically pulp wood using kraft, semi-chemical, sulfite, or soda processes, referred to as MACT I mills, and mills that mechanically pulp wood or pulp secondary or non-wood fibers, referred to as MACT III mills. The regulations require mills to collect and incinerate pulping process vent emissions, collect and control bleaching process vent emissions with a caustic scrubber, and collect and treat process condensate streams to remove HAPs through biological treatment or steam stripping for kraft mills.

In addition to NESHAP, businesses in the paper industry must also comply with other regulations and permits, such as the pollution prevention and control (PPC) permit, which includes conditions relating to odour and emissions to air, and the requirement to not use ozone-depleting substances (ODS) for degreasing or solvent applications.

Reducing energy demands: Using anaerobic digesters to recycle water

The paper and pulp industry is one of the most polluting industries in the world, particularly due to the discharge of hazardous chemical compounds in wastewater. To reduce air pollutants from paper production, businesses can implement various measures, such as obtaining a pollution prevention and control (PPC) permit and complying with regulations on emissions and the use of organic solvents and F gases.

One way to reduce energy demands and recycle water in the paper production process is by using anaerobic digesters. Anaerobic digestion is a process where bacteria break down organic matter, such as animal manure, wastewater biosolids, and food waste, in the absence of oxygen. The process takes place in a sealed vessel called a reactor, which can be designed in various shapes and sizes to suit specific site requirements and feedstock conditions.

The organic waste is fed into a crusher unit, mixed with a small amount of water, and then fed into the bio-digester, where archaea microorganisms break it down to produce biogas and digestate. Biogas, composed primarily of methane, can be used to generate electricity and power cooling systems, among other uses. Digestate, on the other hand, is the nutrient-rich solid or liquid material remaining after the digestion process. It can be used as animal bedding, fertilizer, compost, or soil amendment, providing revenue and environmental benefits.

By using anaerobic digesters to treat wastewater, the paper industry can recycle water, reduce water consumption, and lower energy demands. Additionally, the use of anaerobic digestion can help address the issue of water pollution and freshwater scarcity, contributing to water sustainability and bringing environmental, economic, and social benefits.

Avoiding landfill: Recycling mixed paper

The paper industry is the most polluting industry in the world due to the discharge of hazardous chemical compounds in wastewater after pulp and paper production. The pulp and paper industry in India, for example, consists of around 859 small and large units. The paper industry produces a huge amount of waste for each ton of paper produced, and it is the main consumer of plant wood, electricity, and water.

Recycling mixed paper is one of the easiest ways to help the environment. Paper makes up about a quarter of all trash in the US, and nearly 20 million tons of mixed paper ends up in landfills each year. However, paper also has one of the highest recycling rates of all materials. According to the American Forest & Paper Association (AF&PA), 68% of paper used in the United States was recycled in 2022.

To avoid contaminating the recycling stream, only clean, dry paper is appropriate for mixed paper recycling. Wet, greasy, or food-stained paper can ruin entire batches, forcing recycling facilities to send good paper to the landfill. Items like greasy pizza boxes, fast-food wrappers, paper plates, and used paper cups should be disposed of in the trash. Frozen food boxes are coated with plastic and belong in the trash. Paper towels and napkins can be composted, and switching to reusable options, like cloth napkins, can further reduce landfill contributions.

Businesses can work directly with a recycling company to ensure they are complying with the recycling guidelines established by their municipality. Providing plenty of highly visible, clearly marked recycling containers can also encourage everyone at the workplace to recycle properly.

Pollution prevention: Using pollution control methods like scrubbers and chemical recovery systems

Paper production is a highly resource-intensive process that generates significant waste and environmental challenges. Pulp mills and paper production facilities are large sources of standard air pollutants, such as carbon dioxide, nitrous oxides, carbon monoxide, sulfur dioxide, and particulate matter. Additionally, the use of toxic chemicals, such as solvents and chlorine compounds, in the paper-making process further contributes to air pollution.

To address these issues, pollution control methods like scrubbers and chemical recovery systems play a crucial role in preventing and mitigating air pollution in the paper production industry.

Scrubbers

Scrubbers are devices used to remove airborne pollutants and particulate matter from industrial exhaust streams. Wet scrubbers, in particular, are commonly employed in various industries, including paper production, to minimize environmental impact and human safety risks associated with air pollution. Here's how scrubbers help:

• Wet scrubbers use a spray of water or other liquids to trap and wash out suspended particles from the airstream.
• Venturi scrubbers, a type of wet scrubber, are highly efficient in removing particles larger than 0.5 μm in diameter, achieving efficiencies of more than 98%.
• By regulating particulate matter quantity, scrubbers help reduce haziness and improve visibility.
• Wet scrubbers can remove harmful inorganic gases, such as chromic acid, hydrogen sulfide, and sulfur dioxide, which are designated as priority pollutants by environmental protection agencies.
• Wet scrubbers are also effective in minimizing industrial volatile organic compound (VOC) content, creating cleaner and safer air. VOCs are human-made chemicals released during specific manufacturing processes, including paint, pharmaceuticals, and refrigerants.
• The construction materials and designs of scrubbers influence their efficiency and longevity. For instance, Teflon-lined scrubbers are suitable for extreme-temperature environments.

Chemical Recovery Systems

Chemical recovery systems are a set of processes and technologies designed to extract and reuse valuable chemicals from the waste streams generated during the pulping process. By adopting efficient chemical recovery systems, pulp mills can achieve multiple benefits:

• Chemical recovery helps prevent the pollution of waterways and air, thereby protecting aquatic ecosystems and reducing the industry's carbon footprint.
• By recovering and reusing chemicals, chemical recovery systems reduce the need for harvesting additional trees and raw materials, conserving resources and minimizing waste.
• Chemical recovery systems enable pulp mills to align with stringent environmental regulations and sustainability objectives, enhancing their reputation and marketability among environmentally conscious customers and investors.
• Chemical recovery processes are constantly evolving, with advancements in evaporation techniques, smelting technology, and the optimization of chemical recovery furnaces to increase energy efficiency and further reduce emissions.

Using alternative materials: Reducing the use of toxic chemicals like chlorine and mercury

The paper industry is one of the most polluting industries in the world, largely due to the use of toxic chemicals and the discharge of hazardous chemical compounds in wastewater. Chlorine and mercury are among the most commonly used toxic chemicals in paper production, and their use has been associated with negative environmental and health impacts.

In the past, paper mills that used elemental chlorine produced large quantities of dioxins, which are highly toxic organic pollutants. These dioxins are released into the environment, contaminating water sources and accumulating in the food chain, with serious health consequences for humans, including reproductive, developmental, immune, and hormonal problems.

To address this issue, since the 1990s, the paper industry has been transitioning towards reducing and eliminating the use of elemental chlorine in the delignification process. This has been achieved by adopting ECF (Elemental Chlorine Free) and TCF (Totally Chlorine Free) bleaching processes. TCF bleaching completely removes chlorine from the process, reducing chlorinated organic compounds to background levels in pulp mill effluent. While ECF bleaching does not entirely eliminate these compounds, it can significantly reduce their presence.

In terms of mercury, it is used in the production of chlorine and sodium hydroxide or potassium hydroxide from salt brine. The mercury-cell process, as it is known, has been widely used, but alternative non-mercury processes, such as the membrane and diaphragm processes, have been available since the 1980s. Due to the environmental and health risks associated with mercury, there have been global efforts to reduce its use. For instance, the Minamata Convention on Mercury and the EU's Regulation (EU) 2017/852 have implemented bans on the use of mercury in chlorine production and the export of metallic mercury.

By adopting these alternative processes and technologies, the paper industry can significantly reduce the use of toxic chemicals like chlorine and mercury, thereby minimizing their negative impact on the environment and human health.
