Air Quality Monitoring: Detecting Harmful Pollutants

Air pollution is a pressing issue that poses a significant threat to human health and the environment. With increasing emissions worldwide, it is crucial to detect and address air pollutants to mitigate their impact. Air quality monitoring plays a vital role in this process, providing data that helps us understand the extent and nature of air pollution. This data is essential for informing policies, strategies, and interventions aimed at improving air quality and protecting public health. Various methods and technologies are employed to detect air pollutants, including low-cost sensors, satellite imaging, and laser scanning. These tools enable the measurement of specific pollutants, such as particulate matter (PM), carbon dioxide, and other harmful substances, allowing for a more targeted and effective approach to combating air pollution and safeguarding the well-being of communities.

Low-cost air pollution monitors

While low-cost air pollution monitors can provide valuable insights into indoor air quality, it is important to note that they have limitations. Currently, there is limited information on how well some of these monitors detect pollutants indoors, and they may not provide a complete representation of indoor air quality. For example, a monitor designed to measure PM may not alert you to the presence of other harmful pollutants like radon or carbon monoxide. Therefore, it is important for consumers to understand the potential benefits and limitations of low-cost air pollution monitors and how to interpret the data they provide.

Despite these limitations, advances in air sensor technology have made low-cost air pollution monitors increasingly valuable tools for assessing indoor air quality and taking action to improve it. As technology continues to evolve, sensors are becoming smaller, less expensive, and more widely available, providing new insights into the complex mixture of gases, particles, and chemicals present in our homes and communities.

Air Quality Index (AQI)

Air pollution is a growing concern, threatening human health and contributing to climate change, biodiversity loss, and pollution. According to the World Health Organization, 99% of the global population breathes unclean air, and air pollution causes seven million premature deaths annually.

The Air Quality Index (AQI) is a tool used to communicate about outdoor air quality and health. The AQI is designed by the Environmental Protection Agency (EPA) and includes six color-coded categories, each corresponding to a range of index values. The higher the AQI value, the greater the level of air pollution and the more significant the health concern.

For instance, an AQI value of 50 or below represents good air quality, while a value over 300 indicates hazardous air quality. When AQI values exceed 100, the air quality is considered unhealthy, initially for certain sensitive groups of people, and then for everyone as values increase. Each category corresponds to a different level of health concern, with a specific color to enable people to quickly assess the air quality in their communities.

The AQI is calculated using data from air quality monitors, which are outfitted with sensors designed to detect specific pollutants. Some monitors use lasers to scan particulate matter density in a cubic meter of air, while others rely on satellite imaging to measure energy reflected or emitted by the Earth. These monitors provide data on specific pollutants, such as particulate matter (PM) or carbon dioxide, and environmental factors like temperature and humidity.

It is important to note that low-cost air pollution monitors may have limitations in detecting all pollutants, and their effectiveness can vary indoors. To address the global air pollution crisis, strengthening air quality regulation and monitoring capacity is crucial, especially in regions with sparse monitoring, such as Africa, Central Asia, and Latin America.

Health impacts of air pollution

Air pollution is a mix of hazardous substances from both human-made and natural sources. It is the presence of one or more contaminants in the atmosphere, such as dust, fumes, gas, mist, odour, smoke or vapour, in quantities and durations that can be harmful to human health.

The World Health Organization (WHO) reports that 99% of the global population breathes unclean air, and air pollution causes around 7 million premature deaths annually. This number has increased over the past two decades, with more than 6.5 million deaths attributed to air pollution each year. The main pathway of exposure from air pollution is through the respiratory tract. Pollutants enter the body through the lungs and can circulate throughout the entire body via the bloodstream, leading to systemic inflammation and carcinogenicity. Almost every organ in the body can be impacted by air pollution.

Fine particulate matter, such as PM2.5, poses the greatest health threat. These particles are 30 times thinner than a human hair and can be inhaled deeply into the lungs, contributing to serious health problems. Short-term exposure to higher levels of outdoor air pollution is associated with reduced lung function, aggravated asthma, cardiac problems, and emergency department visits. Long-term exposure increases the risk of noncommunicable diseases, including stroke, heart disease, chronic obstructive pulmonary disease, and cancer.

Other health risks associated with air pollution include diabetes, neurological development issues, reproductive, immune system, and cardiovascular disorders. Maternal exposure to air pollution is linked to adverse birth outcomes, such as low birth weight, pre-term birth, and small gestational age births. Additionally, psychosocial stress, poverty, racial/ethnic discrimination, and residency status can amplify the harmful effects of air pollution.

To address this crisis, urgent action is required from governments to strengthen air quality regulations, including monitoring capacity to track PM2.5 and other pollutants. The Air Quality Index (AQI) is a tool used to communicate about outdoor air quality and health, with higher AQI values indicating greater levels of air pollution and health concerns.

Satellite imaging

Satellite data can be used to estimate emissions, track pollutant plumes, support air quality forecasting, monitor long-term trends, and evaluate air quality model outputs. They can also help identify air pollution hotspots, study health effects, and track air pollution trends.

One example of a satellite imaging tool is NASA's Moderate Resolution Imaging Spectroradiometer (MODIS), which records the location of fires on the ground by observing unusual hotspots. MODIS can also be used to track the transport of pollutants and smoke from fires, as well as to identify areas of haze, which may be caused by local traffic, industry, or pollution from other regions.

Another example is the Multi-angle Imaging SpectroRadiometer (MISR), which has been used to estimate PM2.5 species concentrations (such as sulfate, nitrate, organic carbon, and elemental carbon) in Southern California from 2001 to 2015.

Recent advances in satellite technology have enabled the development of multi-modal AI models, such as AQNet, which fuses ground measurements and satellite data to create an "air-quality index" for comparing air quality over different regions. This model has been trained using a dataset of European pollution monitoring station measurements, including features such as altitude, population density, and environmental classification of local areas.

Laser scanning

Laser spectroscopic technology has been used for decades to track individual compounds. However, researchers at the National Institute of Standards and Technology (NIST) have developed a system that can simultaneously measure multiple gases. This system, known as a laser frequency-comb instrument, can detect and measure gases like nitrous oxide, carbon dioxide, water vapour, ozone, and carbon monoxide. The ability to measure multiple gases at once is a significant advantage over traditional methods that can only analyse one gas or pollutant at a time.

Laser air particle counters are another application of laser scanning for detecting air pollutants. These devices use scattered light technology to detect and measure the size and quantity of particles in the air. They operate by directing a laser through a flow of air, where the particles in the air deflect the laser's light. By measuring the deflections of light, the particle size and concentration can be determined. These counters can detect particles as small as 0.3 microns, including common allergens like pollen, dust, pet dander, and mould spores.

The development of laser detection technology has led to significant progress in air pollution monitoring. Techniques such as long-path measurements, laser Raman (differential absorption) measurements, and optoacoustic detection have provided valuable data for understanding and mitigating air pollution. The high precision and versatility of laser scanning make it a powerful tool for detecting and analysing air pollutants, contributing to improved air quality monitoring and management.
