Air Pollution: Measurement And Definition Explained

Air pollution is a serious issue that affects billions of people worldwide, and it is important to be able to measure it to understand its impact on the environment and human health. Air pollution measurement is the process of collecting and measuring the components of air pollution, such as gases and particulates. There are many different ways to measure air pollution, from simple, low-cost passive devices like diffusion tubes to highly sophisticated chemical and physical sensors. These sensors can provide almost real-time pollution measurements, which are used to generate air quality indexes like the Air Quality Index (AQI) or the U.S. Environmental Protection Agency's (EPA) AQI. These indexes help communicate the level of air pollution and associated health risks to the public. The data collected by these devices and sensors is essential for creating policies to control and reduce air pollution, protecting public health, and mitigating the economic impacts of pollution.

Passive and active measurement

Air pollution is broadly measured in two ways: passively or actively. Passive devices are relatively simple and inexpensive. They collect samples of ambient air, which are then analysed in a laboratory. Diffusion tubes, fastened to lamp posts, are a common form of passive measurement. They absorb specific pollutant gases, which are then analysed in a laboratory. Deposit gauges, large funnels that collect soot and other particulates, are another type of passive device.

Active measurement devices are automated or semi-automated and tend to be more complex and sophisticated than passive devices. They use fans to suck in the air, filter it, and either analyse it automatically or store it for later analysis. Active sensors use either physical or chemical methods. Physical methods measure an air sample without changing it, for example by seeing how much of a certain wavelength of light it absorbs. Chemical methods change the sample through a chemical reaction and measure that. Most automated air-quality sensors are examples of active measurement.

Air pollution is also assessed more qualitatively by observing the effect of polluted air on growing plants such as lichens and mosses (an example of biomonitoring). Some scientific projects have used specially grown plants such as strawberries. The amount of pollutant present in the air is usually expressed as a concentration, measured in either parts-per notation (usually parts per billion or parts per million, also known as the volume mixing ratio), or micrograms per cubic meter.

Air quality is measured with the Air Quality Index (AQI), which works like a thermometer that runs from 0 to 500. The higher the AQI value, the greater the level of air pollution and the greater the health concern. For example, an AQI value of 50 or below represents good air quality, while an AQI value over 300 represents hazardous air quality. Each category has a specific colour, making it easy for people to quickly determine whether air quality is reaching unhealthy levels in their communities.

Air Quality Index (AQI)

The Air Quality Index (AQI) is a tool used to communicate information about outdoor air quality and health. The AQI is a scale from 0 to 500 that measures the amount of pollution in the air. The higher the AQI value, the greater the level of air pollution and the more significant the health concerns associated with it. The AQI is divided into six colour-coded categories, each indicating a different level of health concern.

An AQI value of 50 or below represents good air quality, while an AQI value over 300 indicates hazardous air quality. When AQI values are above 100, the air quality is unhealthy for certain sensitive groups of people, and as the AQI value increases, it becomes unhealthy for everyone. The AQI is established for five major air pollutants regulated by the Clean Air Act, and each pollutant has a national air quality standard set by the Environmental Protection Agency (EPA) to protect public health.

AQI values are calculated using data collected by instruments on the ground and satellites orbiting the Earth. Satellites, such as those in the NOAA's GOES-R series, monitor particle pollution in the atmosphere, while the Joint Polar Satellite System (JPSS) collects information about particles in the air, including smoke particles from wildfires, airborne dust, urban and industrial pollution, and ash from volcanic eruptions. These satellites provide frequent measurements of particle pollution, offering valuable data for AQI calculations.

The AQI is an essential tool for monitoring air quality and protecting public health. By providing a standardised scale and colour-coded categories, the AQI helps individuals and communities quickly assess the air quality in their local areas and take appropriate actions to protect their health when necessary.

Hydrocarbon measurement

Hydrocarbons are organic compounds that occur naturally in the environment and are composed of two elements: hydrogen and carbon. They are often used as primary sources of fuel, such as methane, butane, propane, and hexane. Hydrocarbons can become air pollutants during the combustion of fuel sources, but the most common cause of hydrocarbon contamination is the spillage of crude oil or other industrial commodities. This can occur on oil platforms and tankers, as well as through agricultural runoff and stormwater discharge.

The measurement of hydrocarbon air pollution is crucial to understanding its impact on the environment and human health. Here are some methods and technologies used to measure hydrocarbon pollution:

• Passive Measurement Devices: These are relatively simple and low-cost devices that passively collect samples of ambient air for subsequent analysis in a laboratory. One common type of passive device is the diffusion tube, which is fastened to structures such as lamp posts to absorb specific pollutant gases, including hydrocarbons.
• Active Measurement Devices: These devices are automated or semi-automated and tend to be more complex and sophisticated than passive devices. They use fans to collect air samples, filter them, and either analyze them immediately or store them for later laboratory analysis. Active sensors use physical or chemical methods for measurement. Physical methods, such as measuring light absorption, do not alter the sample, while chemical methods involve a chemical reaction to measure the sample.
• Air Quality Sensors: These range from small handheld devices to large-scale static monitoring stations. They constantly sample particulates and gases, providing real-time measurements of air quality. Some examples include the Air Quality Egg and PurpleAir sensors.
• Satellite Remote Sensing: Satellites, such as those in the Joint Polar Satellite System (JPSS), collect information about particles in the air, including smoke particles from wildfires, airborne dust, urban and industrial pollution, and volcanic ash. These satellites can also measure ground-level ozone, which is a component of smog and can have negative health impacts.
• Mass Spectrometry: This technique is widely used to measure organic compounds, including polyaromatic hydrocarbons (PAHs). It involves separating samples using gas chromatography (GC) and then detecting individual ions based on their mass-to-charge ratio. Mass spectrometry can be combined with other techniques, such as gas chromatography, to identify thousands of organic species accurately.
• Hotspot Identification: This involves identifying locations within a community where pollutant concentrations are significantly higher than in the surrounding areas. Hotspots are typically centered around emission sources and may require more robust monitoring methods. Technologies used for hotspot identification include mobile monitoring, satellite remote sensing, dense networks of air sensors, and fixed monitoring sites.

By employing these measurement techniques, environmental scientists and regulators can gain valuable insights into the levels and impacts of hydrocarbon pollution. This information is crucial for developing strategies to mitigate hydrocarbon pollution and protect both the environment and public health.

PM2.5 concentration

Air pollution measurement is the process of collecting and measuring the components of air pollution, such as gases and particulates. Modern air pollution measurement is largely automated and carried out using various devices and techniques.

One of the key metrics used to assess air quality is PM2.5 concentration, which refers to the concentration of fine particulate matter with a diameter of 2.5 micrometres or less. These fine particles are a mixture of solid and liquid particles suspended in the air, often composed of inorganic ions, metallic compounds, elemental carbon, organic compounds, and compounds from the earth's crust. Due to their small size, PM2.5 particles can remain suspended in the air for extended periods and penetrate deep into the respiratory tract, reaching the lungs and even entering the bloodstream.

The health risks associated with PM2.5 exposure are significant. Short-term exposure to elevated levels of PM2.5 has been linked to premature mortality, increased hospital admissions for heart and lung issues, acute and chronic bronchitis, asthma attacks, and respiratory symptoms. Long-term exposure to PM2.5 may also contribute to reduced lung function and increased mortality from lung cancer and heart disease. People with pre-existing breathing and heart problems, children, and the elderly may be especially vulnerable to the adverse effects of PM2.5.

To ensure the protection of public health and the environment, organisations like the Environmental Protection Agency (EPA) in the United States establish standards and monitor PM2.5 concentrations. The EPA, for example, operates a nationwide network of monitoring sites to track particle pollution trends and sets national air quality standards under the Clean Air Act.

Historical data analysis

One key aspect of historical data analysis is the evaluation of air pollution levels over extended periods. By collecting and studying data from various sources, such as ground monitoring stations, satellite observations, and emissions inventories, scientists can identify trends in air pollutant concentrations. For example, the World Health Organization (WHO) compiles ground measurements of annual mean concentrations of nitrogen dioxide (NO2) and particulate matter (PM10 and PM2.5) in its air quality database. This data, collected from over 600 human settlements in more than 100 countries, enables the analysis of long-term trends in air pollution levels globally.

Moreover, historical data analysis is essential for assessing the impacts of air pollution on human health and the environment. By analysing long-term data, researchers can establish links between air pollutant levels and health outcomes, such as respiratory infections, lung cancer, and cardiovascular diseases. For example, the Global Burden of Disease study by the Institute for Health Metrics and Evaluation (IHME) estimates the number of deaths attributed to air pollution and other risk factors. This helps in quantifying the health burden of air pollution and informing public health policies and interventions.

In addition to health impacts, historical data analysis can reveal the environmental consequences of air pollution. By studying past data, scientists can better understand the effects of air pollution on ecosystems, climate change, and the planet's atmospheric composition. This knowledge is crucial for developing sustainable practices and policies to mitigate the environmental impacts of air pollution.

Furthermore, historical data analysis provides a basis for evaluating the effectiveness of air pollution control measures. By comparing air quality data before and after the implementation of specific regulations or interventions, policymakers can assess their impact on reducing pollution levels. For instance, the phase-out of leaded gasoline and the implementation of air toxics programs in the US led to a significant decrease in airborne lead concentrations, demonstrating the positive outcomes of regulatory actions.
