Atmospheric Inversion: Trapping Air Pollutants And Choking The Sky

Atmospheric inversions, also known as temperature inversions, occur when the normal temperature gradient of the atmosphere is reversed, leading to a layer of warmer air overlaying cooler air. This phenomenon can trap air pollutants near the Earth's surface, resulting in poor air quality and potential health risks. The strength, duration, and height of the inversion layer influence the severity of the resulting pollution. Inversions can suppress convection and hinder the dispersion of pollutants, leading to hazardous conditions, particularly in urban areas. The Great Smog of 1952 in London, caused by a combination of industrial emissions and a temperature inversion, is a notable example, resulting in thousands of estimated deaths and significant policy changes.

Inversions occur when the normal temperature gradient of the atmosphere is reversed

Inversions, also known as temperature inversions, occur when the normal temperature gradient of the atmosphere is reversed. Typically, the air closest to the Earth's surface is warm and becomes colder as altitude increases. However, during an inversion, a layer of warm air is trapped beneath a layer of cold air, creating a pocket of stagnant air near the surface. This phenomenon can occur when a warm, less dense air mass moves over a cooler, denser air mass, as often happens near warm fronts and in areas of oceanic upwelling. Inversions can also occur when radiation from the Earth's surface exceeds the amount of incoming solar radiation, which commonly happens at night or during winters when the sun is low in the sky. This effect is largely confined to land regions, as oceans retain heat for longer.

Temperature inversions can have a significant impact on air pollution levels. The warm inversion layer acts as a cap, preventing air pollutants from dispersing into the upper atmosphere. The strength, duration, and height of the inversion layer determine the severity of the resulting pollution. A stronger inversion, with a greater temperature difference between layers, inhibits the dispersal of pollutants into higher atmospheric levels. Similarly, the longer an inversion lasts, the more pollution accumulates, leading to deteriorating air quality.

Inversions can have particularly detrimental effects in cities, which produce more atmospheric pollutants and have higher thermal masses than rural areas. As a result, inversions occur more frequently in urban areas, and the concentration of pollutants can be significantly higher. The presence of surrounding hills or mountains further exacerbates the problem by creating an additional barrier to air circulation.

The Great Smog of 1952 in London, England, is a well-known example of the severe consequences of temperature inversions. During this event, an anticyclone and windless conditions created an inversion that trapped pollutants from the extensive burning of cheap, sulfurous coal. The resulting smog is estimated to have caused the deaths of up to 12,000 people and led to significant policy changes in the United Kingdom, including the Clean Air Act of 1956.

Temperature inversions can stop atmospheric convection

Temperature inversion is a reversal of the typical behaviour of temperature in the troposphere, where a layer of cool air at the surface is overlain by a layer of warmer air. Ordinarily, the temperature of the air decreases with height. Inversions act as a cap on the upward movement of air from the layers below, limiting the convection produced by the heating of air from below to levels beneath the inversion. This also limits the diffusion of dust, smoke, and other air pollutants, which can lead to high concentrations of atmospheric pollutants.

In regions where a pronounced low-level inversion is present, convective clouds cannot grow high enough to produce showers. Visibility may also be significantly reduced below the inversion, even in the absence of clouds, due to the accumulation of dust and smoke particles. This is particularly true in cities, which produce more atmospheric pollutants and have higher thermal masses than rural areas, resulting in more frequent inversions with higher concentrations of pollutants. The effects are even more pronounced when a city is surrounded by hills or mountains, as they form an additional barrier to air circulation.

A ground inversion occurs when air is cooled by contact with a colder surface until it becomes cooler than the overlying atmosphere. This commonly happens on clear nights when the ground cools off quickly by radiation. The topography greatly affects the magnitude of ground inversions. If the land is hilly or rolling, the cold air formed on the higher surfaces tends to drain into the hollows, producing a larger and thicker inversion above the low ground and little to none above higher elevations.

A subsidence inversion occurs when a widespread layer of air descends and is compressed and heated by the resulting increase in atmospheric pressure, leading to a reduced lapse rate of temperature. A turbulence inversion forms when quiescent air overlies turbulent air. Within the turbulent layer, vertical mixing carries heat downward, cooling the upper part of the layer. The unmixed air above remains warmer than the air below, creating an inversion.

The strength, duration and height of an inversion layer determine the severity of a pollution event

The strength, duration, and height of an inversion layer are key factors in determining the severity of a pollution event. An inversion layer is a layer of warm air that acts as a lid, trapping pollutants beneath it and preventing them from mixing into the rest of the atmosphere. The strength of an inversion layer refers to the thermal difference between the inversion and mixing layers. A stronger inversion, with a greater thermal difference, prevents pollution from dispersing into higher atmospheric levels. Consequently, a greater amount of pollution becomes trapped within the inversion layer, leading to a more severe pollution event.

The duration of an inversion layer also plays a crucial role in the severity of a pollution event. The longer an inversion lasts, the more pollution accumulates beneath it. This prolonged build-up of pollutants results in a significant deterioration in air quality within the mixing layer. For example, during the Great Smog of 1952 in London, an anticyclone and windless conditions caused a prolonged thermal inversion, trapping particulates, sulfur oxides, and hydrochloric acid in the air and resulting in a thick layer of deadly smog that lasted for days and caused thousands of deaths.

The height of the inversion layer is another determining factor. A low inversion layer results in a smaller mixing layer, leading to higher concentrations of pollutants within that space. This concentration of pollutants can reach dangerous levels, further exacerbating the severity of the pollution event. Conversely, a higher inversion layer allows for a larger mixing layer, providing more volume for the pollutants to disperse, thereby reducing their concentration and potentially mitigating the severity of the pollution event.

It is important to note that the severity of a pollution event is influenced not only by the characteristics of the inversion layer but also by the levels of pollution present in the area. In areas with high levels of pollution, even a relatively weak, short-lived, or high inversion layer can result in a significant pollution event due to the sheer volume of pollutants available to become trapped within the inversion layer.

Inversions can cause freezing rain in cold climates

Inversions, or temperature inversions, are meteorological phenomena where a layer of warm air overlies cooler air near the Earth's surface. This is a reversal of the typical relationship between air temperature and altitude, where temperature decreases as altitude increases. Inversions can cause freezing rain in cold climates through specific atmospheric conditions.

Freezing rain is a weather phenomenon that occurs when falling snow or supercooled raindrops pass through a layer of warm air, melting completely, and then encounter a thin layer of cold air just above the Earth's surface, cooling to below-freezing temperatures. As the raindrops approach the ground, they become supercooled, remaining liquid despite being colder than 0°C. When these supercooled raindrops come into contact with frozen surfaces, they instantly freeze, forming a thin film of ice. This process results in freezing rain, which can make surfaces extremely slick and hazardous.

The formation of freezing rain is closely linked to temperature inversions. In cold climates, temperature inversions can create the necessary conditions for freezing rain to occur. Typically, the air near the Earth's surface is warmer than the air above due to solar radiation heating the ground, which then warms the lower atmosphere. However, during a temperature inversion, this relationship is reversed, with a layer of warm air overlaying cooler air near the surface. This inversion layer can act as a cap, suppressing convection and trapping pollutants near the ground.

When warm oceanic air rises over a layer of cold air, it creates the perfect conditions for freezing rain. This warm air encounters snow or supercooled raindrops, melting them into liquid precipitation. As this liquid precipitation falls through the cold air layer, it undergoes supercooling, remaining liquid even below 0°C. Eventually, when these supercooled droplets strike frozen surfaces, they freeze instantly, leading to the formation of freezing rain.

Topography also plays a role in the occurrence of freezing rain. In hilly or mountainous regions, cold air tends to drain into lower areas, creating a larger and thicker inversion layer above low ground. This topographic effect can enhance the conditions for freezing rain development. Additionally, cities are particularly susceptible to temperature inversions due to their higher thermal masses and increased atmospheric pollutant production. The presence of surrounding hills or mountains further exacerbates the inversion effect, creating an additional barrier to air circulation.

Inversions can make sounds travel further

Inversions, or temperature inversions, can make sounds travel further. This is due to the ''sandwich effect'' that is created when there is an inversion. Normally, air gets cooler with altitude, but during an inversion, a layer of warm air is trapped above a layer of cool air close to the ground. This results in sound, light, and radio waves getting bounced between the top of the cool lower layer of air and the ground, making sounds travel further and seem louder.

The curved paths that sound waves take during an inversion cause distant sources of noise to sound much closer than they actually are. The speed of sound in an inversion layer is higher at higher altitudes, and the skyward paths that touch the ground during an inversion help with long-distance sound travel. This effect is most noticeable when the direct path along the ground is blocked by structures or terrain.

For example, during temperature inversions, you may be able to hear noises from distant roads, trains, or aircraft that you wouldn't normally hear. The effect can be even more dramatic if there are very loud noises, such as explosions. In 1955, a nuclear weapon test in Russia created a shock wave that bounced back off the inversion layer, knocked over a building, and killed its three occupants.

It's important to note that wind can impact this phenomenon. Inversions don't exist near the ground when wind speeds are high, and wind can have other effects on sound propagation. Therefore, when observing this phenomenon, it is recommended to disregard windy conditions and focus on calm, clear conditions, which is when temperature inversions typically occur.
