Lasers And Pollution: What's The Real Damage?

Laser beams are a common feature of modern life, from medical applications to laser pointers. However, they can be a source of pollution and hazard in several ways. The most well-known hazard is direct exposure of the eyes or skin to a laser beam, which can cause irreversible damage. In addition, there are non-beam hazards, such as the risk of fire when a laser beam strikes a combustible material, the release of airborne contaminants, and electrical hazards. As laser technology becomes more prevalent, it is important to understand the potential risks and take appropriate safety measures to mitigate these hazards and prevent pollution.

Laser beams can cause eye damage

Laser beams can cause irreversible eye damage. The eye is the organ most sensitive to light. The lens in the human eye focuses the laser beam into a tiny spot that can burn the retina. Even a low-power laser in the milliwatt range can cause a burn if focused directly onto the retina. The eye's cornea, retina, and lens are the components most susceptible to laser damage. Damage to the cornea may be uncomfortable or painful, but will usually heal quickly. However, damage to deeper layers of the cornea may cause permanent injury.

Photochemical injury to the cornea by ultraviolet exposure may result in photokeratoconjunctivitis (often called welder's flash or snow blindness). This painful condition may last for several days and is very debilitating. Long-term UV exposure can also cause cataract formation in the lens. The duration of exposure plays a role in eye injury. For example, if the laser is a visible wavelength (400 to 700 nm), the beam power is less than 1.0 mW, and the exposure time is less than 0.25 seconds (the human aversion response time), no injury to the retina would be expected.

The severity of biological damage caused by lasers depends on several factors, including exposure duration, wavelength of the beam, energy of the beam, and the area and type of tissue exposed to the beam. Beam exposure may also cause photochemical effects when photons interact with tissue cells, potentially resulting in tissue damage or changes.

Specular reflections from mirror surfaces can be nearly as harmful as exposure to the direct beam, particularly if the surface is flat. Curved mirror-like surfaces will widen the beam, increasing the area for possible exposure. While the exposed eye or skin does not absorb the full impact of the beam, the reflected beam may still be harmful, especially for high-powered lasers.

Laser beams can cause skin damage

Lasers can cause skin damage, and the risks are significant enough that laser safety standards have been implemented to protect users. The skin is the body's largest organ, and as such, it is at the greatest risk of coming into contact with a laser beam. The hands, head, and arms are the most likely body parts to be exposed.

The effects of lasers on the skin depend on the power density of the beam, the absorption of tissues at the wavelength, the time the beam is held on the tissue, and the effects of blood circulation and heat conduction in the affected area. The severity of the damage is also influenced by the exposure duration, the beam's wavelength and energy, and the type of tissue exposed. Lasers can harm the skin via photochemical or thermal burns. Depending on the wavelength, the beam may penetrate both the epidermis and the dermis.

Photochemical injuries are caused by excessive levels of actinic ultraviolet radiation, resulting in a sunburn-like effect. Wavelengths of less than 550 nm can cause this type of injury. Photochemical effects are cumulative and result from long exposures (over 10 seconds) to diffuse or scattered light. Some individuals with photosensitivity or those taking certain medications may be more susceptible to photochemical injuries.

Thermal injuries, on the other hand, are caused by a rise in temperature following the absorption of laser energy. This can lead to tissue vaporization and the creation of a mechanical shockwave that propagates through the tissue, causing damage.

The possibility of adverse effects from repeated or chronic laser irradiation to the skin has been suggested, although it is often discounted. Only optical radiation in the ultraviolet region of the spectrum has been consistently shown to cause long-term, delayed effects, including accelerated skin aging and skin cancer.

It is important to note that laser devices can be extremely dangerous if used improperly. Users should always follow safety guidelines and never point a laser at someone's eyes, regardless of the laser's power.

Laser beams can cause fires

Class 3B lasers generally do not pose a fire hazard, while Class 4 lasers do. Enclosure of Class 4 laser beams can result in potential fire hazards if enclosure materials are likely to be exposed to irradiances exceeding 10 W/cm2 or beam powers exceeding 0.5 W. Under some situations where flammable compounds or substances exist, it is possible that fires can be initiated by Class 3B lasers.

Specular reflections from mirror surfaces can be nearly as harmful as exposure to the direct beam, particularly if the surface is flat. Curved mirror-like surfaces will widen the beam, reducing the impact on the exposed surface but increasing the area exposed. A diffuse surface will reflect the laser beam in many directions. Mirror-like surfaces that are not completely flat, such as jewelry or metal tools, may cause diffuse reflections of the beam. These reflections do not carry the full power or energy of the primary beam but may still be harmful, especially for high-powered lasers. Diffuse reflections from Class 4 lasers are capable of initiating fires.

Electrical equipment used in laser applications also presents a risk of fire. Electrical equipment hazards include electrocution, resistive heating, ignition of flammable materials, and arc flash.

Laser beams can cause airborne contaminants

The size of the particles generated by lasers can range from 0.1 to 2.0 µm, with nanoparticles being smaller than 100 nanometers in size. Due to their microscopic size, nanoparticles can easily travel to the deepest parts of the lungs and may even migrate to other parts of the body. This can pose serious health risks, especially to laser operators and healthcare personnel present in the laser operating room. It is important to note that even Class 3B lasers, which typically do not pose a fire hazard, can generate airborne contaminants under certain conditions.

The release of contaminants can occur through various mechanisms, including thermal, mechanical, and photochemical processes. For example, the heat generated by the laser can cause tissue cell disruption, releasing a plume containing viable bacteria, viruses, cellular debris, particulates, and toxic aerosols, gases, or fumes. Mechanical manipulation using rotary devices or saws can also generate airborne contaminants. Additionally, the reflection of laser beams from mirror surfaces or jewelry can increase the area of potential exposure, contributing to the release of contaminants.

To mitigate the risks associated with laser-generated airborne contaminants, proper scavenging systems and control measures must be in place. The laser safety officer (LSO) plays a crucial role in ensuring industrial hygiene aspects are addressed and that safety data sheets (SDS) from the manufacturer are referenced. Additionally, the LSO should be familiar with relevant standards, such as the OSHA standard 29 CFR 1910 Subpart Z, which outlines chemical substance threshold limits. By following these guidelines, the potential health hazards associated with laser-generated airborne contaminants can be minimized.

Laser beam hazards in the workplace

Laser beams can cause significant damage to the eyes and skin, and they can also cause fires under certain conditions. The hazards of lasers can be separated into two general categories: beam-related hazards and non-beam hazards.

Beam-related hazards

The major danger of laser light is hazards from beams entering the eye. The eye is the organ most sensitive to light, and the lens in the human eye can focus the laser beam into a tiny spot that can burn the retina. Even low-power lasers can cause burns if focused directly onto the retina. The cornea, a transparent layer of tissue covering the eye, can heal quickly from minor injuries but can also suffer permanent damage if the deeper layers are affected. Visible and near-infrared lasers are the most likely to cause retinal injuries, as their wavelengths match those that the cornea and lens are transparent to. Wavelengths of less than 550 nm can cause photochemical injuries similar to sunburn, which result from long exposures (over 10 seconds) to diffuse or scattered light.

The skin can also be harmed by lasers via photochemical or thermal burns. Thermal burns are rare and usually require exposure to high-energy beams for an extended period. Carbon dioxide and other infrared lasers are most commonly associated with thermal burns, as their wavelengths can penetrate deeply into skin tissue. Burns can range from first-degree (reddening) to third-degree (charring).

Non-beam hazards

Non-beam hazards refer to all hazards arising from the presence of a laser system, excluding direct exposure of the eyes or skin to a laser beam. These hazards can be physical, chemical, or biological.

Physical hazards include limited workspace, which can create trip and slip hazards from wires and cables on the floor. Laser facilities can also pose hazards due to obstacles, ambient lighting, confined workplaces, indoor temperature, and humidity.

Chemical hazards can be caused by the release of contaminated air during laser processes. While a LEV system can be used to draw and filter out contaminated air, it may not be 100% efficient.

Biological hazards include laser-target interaction radiation, which is emitted by material exposed to a laser beam. This can include plasma radiation and X-ray radiation, which may lead to activation of ionizing radiation.

Electrical equipment used in laser processes also presents several potential hazards, including electrocution, resistive heating, ignition of flammable materials, and arc flash.

In addition, lasers can pose a fire hazard under certain conditions. A fire can occur when a laser beam strikes a combustible material such as paper, plastic, rubber, human tissues, or certain chemicals. The risk of fire is greater in oxygen-rich atmospheres and when the three components required for a fire (fuel, oxidizer, and ignition source) are not kept physically separated.

It is important to be aware of these hazards and consult with safety professionals to ensure a safe workplace when working with lasers.
